Main Parameter		C2-35K
Max. swing over bed (mm)		350
Max.Length of work piece (mm)		750
Max. swing over carriage (mm)		190
Spindle bore dia. (mm)		46
Spindle taper		Morse No.6
Spindle speed grade		C type No.6
Spindle speed range (r.p.m.)		30-2000
Main motor power (kw)		3/4.5
Electric knife number		4
Resolution of feed axis (mm)		0.001 (928TC) 0.01 (928TB)
Max. rapid travel speed of feed axis (mm/min)		3000
Max. torgue of axis drive motor (Nm)		X: 9.0 Z: 12
Carriage swing repeat place precision (mm)		0.01
Feed axis repeat place precision (mm)		X: 0.012 Z: 0.016
Work precision	Circle (mm)	0.005
	Column (mm)	160: 0.016
	Plane (mm)	160: 0.010
Surface roughness Ra. (µ m)		2.5-1.6
Taper of tailstock sleeve		Morse No.4
Lathe size ( LXWXH) (mm)		1700X900X1510
