Main Parameter	CJK6241
Max. swing over bed	410mm
Max. swing over gap	202mm
Distance between centers	630/1000mm
Spindle speed	25-2000pin
Hole through spindle	58mm
Spindle taper	Morse 6M.T.NO.6
Knife number of compond rest	4
Min. longitudinal enactment	0.01mm
Max.cross enactment	0.005mm
Threads range (Metric)	t≤4mm
Main drive motor	4kw
Feed range	12-2000mm/min
Data format executive standard	ISO
Program input manner	MDI or Automatic
Program memory	56K
Fast feed speed	3000mm/min
Lathe net weight	1500KG/1700KG
Lathe size (LxWxH) (mm)	2050x1252x2000
	2350x1252x2000
