Main Parameter	CJK6132
Max. swing over bed	320mm
Max. swing over gap	144mm
Distance between centers	500/700mm
Spindle speed	70-2000pin
Hole through spindle	38mm
Spindle taper	MT5#
Knife number of compond rest	4
Min. longitudinal enactment	0.01mm
Max.cross enactment	0.005mm
Threads range (Metric)	t≤2mm
Main drive motor	2.2kw
Feed range	12-2000mm/min
Data format executive standard	ISO
Program input manner	MDI or Automatic
Program memory	56K
Fast feed speed	3000mm/min
Lathe net weight	650kg/700kg
Lathe size (LxWxH) (mm)	1760x1140x2040
	1960x1140x2040
