Type	QUY50	QUY35
Max.Rated Lifting Capacity(kg)	50000	35000
Max.Hoisting Moment(kN.m)	1815	294.92
Main Boom(m)	13-52	10-40
Boom working angle(°)	30-80	30-80
Main lifting(single rope)(m/min)	0-65	0-110
Auxiliary lifting speed(sigle rope)(m/min)	0-65	0-110
Derricking speed(m/min)	0-52	0-55
Max.Torque of engine(°)	20	20
Slewing Speed(r/min)	0-1.5	0-1.5
Max.Trave Ling Speed(Km/h)	0-1.1	0-1.34
Ground Pressure(Mpa)	0.069	0.058
Max.Power of engline(kw)	117.6	117.6
Jib(m)	9.15-15.25	9.15-15.25
Offpet angle of jib(°)	10/30	30
